Understanding the COTS UE Connection Issues in srsRAN

When deploying srsRAN (srsRAN Project), a common challenge arises when attempting to connect Commercial Off-The-Shelf User Equipments (COTS UEs) with bandwidths exceeding 20 MHz. Users often find that while the UE can detect the SSB (Synchronization Signal Block), it fails to attach to the network. This issue has been observed with devices like the Google Pixel 5 and OnePlus 8 5G mmWave, prompting a deeper investigation into the possible causes and solutions. Bandwidth, COTS UEs, and srsRAN are critical components in modern 5G network deployments, and understanding their interplay is essential for successful network operation.

When dealing with these connectivity issues, it’s crucial to examine various aspects of the network configuration and device compatibility. This section delves into the common configurations and potential troubleshooting steps that can help resolve these challenges. From analyzing the gNB configuration files to ensuring hardware compatibility, a systematic approach is key to diagnosing and fixing the connection failures.

Analyzing the gNB Configuration

The gNB (gNodeB) configuration file is the blueprint for your srsRAN setup. It dictates how your base station operates, including the frequencies it uses, the bandwidth it supports, and the network services it offers. A misconfiguration here can lead to UEs failing to attach, especially when dealing with wider bandwidths. Let’s dissect a sample configuration file to understand what parameters are critical and how they influence UE connectivity. Key parameters such as dl_arfcn, band, channel_bandwidth_MHz, and plmn are central to establishing a stable connection. Properly configuring these settings ensures that the UE can correctly identify and connect to the network.

Consider the following snippet from a gNB configuration file:

cu_cp:
 amf:
 addr: 127.0.0.5
 bind_addr: 127.0.0.1
 supported_tracking_areas:
 - tac: 1
 plmn_list:
 - plmn: "00101"
 tai_slice_support_list:
 - sst: 1

ru_sdr:
 device_driver: uhd # The RF driver name.
 device_args: type=x300, num_recv_frames=64,num_send_frames=64
 clock: external # Specify the clock source used by the RF.
 sync: external # Specify the sync source used by the RF.
 tx_gain: 31 # Transmit gain of the RF might need to adjusted to the given situation.
 rx_gain: 28

cell_cfg:
 dl_arfcn: 536020
 band: 7
 channel_bandwidth_MHz: 30
 common_scs: 15
 plmn: "00101"
 tac: 1

In this configuration:

  • dl_arfcn: This parameter specifies the downlink ARFCN (Absolute Radio Frequency Channel Number), which indicates the frequency used for downlink communication. An incorrect value here means the UE might be searching on the wrong frequency.
  • band: The band parameter indicates the frequency band in use. For example, band 7 corresponds to a specific frequency range. Ensuring the UE supports this band is crucial.
  • channel_bandwidth_MHz: This setting defines the channel bandwidth, which is the width of the frequency band used for communication. If set to 30 MHz, as in this example, the UE must support this bandwidth to connect. Incompatibilities in bandwidth support are a common reason for connection failures.
  • plmn: The Public Land Mobile Network identifier. This must match the SIM card’s PLMN for the UE to attach to the network.

Common Pitfalls and Troubleshooting Steps

When a COTS UE fails to connect, several factors could be at play. Here’s a structured approach to troubleshooting:

  1. Bandwidth Compatibility: Begin by verifying that the UE supports the configured channel bandwidth. Many COTS UEs have limitations on the maximum bandwidth they can handle. If the gNB is set to a bandwidth the UE doesn't support, the connection will fail.
  2. Frequency Band Support: Ensure that the UE supports the frequency band specified in the gNB configuration. Different regions and carriers use different bands, and a mismatch here is a common issue.
  3. RF Parameters: Check the RF (Radio Frequency) parameters, including transmit and receive gains. Incorrect gain settings can result in the UE not being able to properly receive or transmit signals.
  4. Synchronization Issues: Synchronization signals are critical for the UE to establish a connection. Verify that the clock and sync sources are correctly configured. External clock and sync sources should be stable and properly connected.
  5. PLMN and TAC Mismatch: The PLMN (Public Land Mobile Network) and TAC (Tracking Area Code) in the gNB configuration must match the SIM card’s settings. A mismatch will prevent the UE from attaching to the network.

Case Studies and Examples

Consider a scenario where a user is trying to connect a Google Pixel 5 to an srsRAN gNB configured for a 30 MHz bandwidth on Band 7. The UE detects the SSB but fails to attach. Here’s how we can approach troubleshooting:

  • Step 1: Verify Bandwidth Support: Check the specifications of the Google Pixel 5 to ensure it supports 30 MHz bandwidth on Band 7. If the UE only supports up to 20 MHz, this is the likely cause.
  • Step 2: Check Frequency Band Support: Confirm that the Google Pixel 5 supports Band 7. If it doesn't, the UE will not be able to communicate on this frequency.
  • Step 3: Review RF Parameters: Ensure the transmit and receive gains are appropriately set. Too low a gain might result in the UE not detecting the gNB, while too high a gain can lead to interference.

Another common issue is a mismatch between the gNB’s PLMN and the SIM card’s PLMN. For example, if the gNB is configured for PLMN “00101” and the SIM card is configured for “00102,” the UE will fail to attach. PLMN mismatch is a frequent oversight in network configurations.

Advanced Configuration and Optimization

Beyond the basic settings, advanced configurations can significantly impact UE connectivity. Here are some areas to consider:

  • Slicing: Network slicing allows you to create multiple virtual networks on the same physical infrastructure. Ensure that the UE supports the network slice configured in the gNB.
  • TAC Planning: Proper TAC (Tracking Area Code) planning is crucial for mobility management. An incorrect TAC configuration can lead to handoff failures and connection drops.
  • Beamforming: If using mmWave frequencies, beamforming is essential for directing the signal towards the UE. Misconfigured beamforming parameters can result in poor signal strength and connection issues.

Community Insights and Support

Engaging with the srsRAN community can provide valuable insights and support. Online forums, mailing lists, and community events are excellent resources for troubleshooting and staying updated on best practices. Sharing your experiences and learning from others can significantly enhance your understanding and ability to resolve connection issues.

Many users have reported similar issues with COTS UEs and wider bandwidths. Common suggestions include:

  • Firmware Updates: Ensure the UE and gNB are running the latest firmware versions. Firmware updates often include bug fixes and performance improvements that can address connectivity issues.
  • Log Analysis: Analyze the logs from both the UE and gNB. Logs can provide detailed information about the connection process and pinpoint where failures occur.
  • Hardware Compatibility: Verify that the hardware components, such as the RF front-end and SDR (Software Defined Radio), are compatible with the configured bandwidth and frequencies.

Future Trends and Developments

The landscape of 5G and srsRAN is continuously evolving. As new devices and technologies emerge, it’s crucial to stay informed about the latest trends and developments. Future advancements in UE capabilities, network configurations, and software implementations will likely address many of the current challenges in COTS UE connectivity.

One promising trend is the increasing support for wider bandwidths in newer UEs. As more devices become capable of handling bandwidths beyond 20 MHz, the issues related to bandwidth incompatibility will likely diminish. Additionally, ongoing improvements in srsRAN and other open-source 5G solutions will provide more robust and flexible network configurations.

Conclusion

Troubleshooting COTS UE connection issues with srsRAN and bandwidths above 20 MHz requires a systematic approach. By carefully analyzing the gNB configuration, verifying hardware and software compatibility, and engaging with the community, you can effectively diagnose and resolve these challenges. Understanding the intricacies of bandwidth support, frequency bands, and RF parameters is essential for ensuring a stable and high-performance 5G network.

For further information and resources, visit the srsRAN Project website at https://www.srsran.com/. This trusted website provides comprehensive documentation, community forums, and updates on the latest developments in srsRAN technology.
